1612 size ultra miniature and weightlight SMD crystal resonator with a low profile of 0.35mm
Wide frequency range from 24MHz up to 54MHz
High precision and high reliability
Automatic mounting and reflow soldering
Applications: Small communication devices, Small mobile devices, Wireless modules, AV equipment, PC, IoT, etc.
RoHS Compliant /Pb-Free
Electrical Specifications Of 7Y Series SMD 1612 Crystal Resonator
Item /Type
7Y (SMD 1612 Crystal Resonator)
Frequency Range
24~30MHz
30~54MHz
Overtone Order
Fundamental
Load Capacitance
8pF, 10pF, or specify
Drive Level
1~200μW (50μW Typ.)
Frequency Tolerance
±10ppm, ±20ppm, or specify
Series Resistance
100Ω
80Ω
Shunt Capacitance
-20~+70℃, or specify
Operating Temperatuer
5pF Max.
Storage Temperatuer
-55~125℃
Aging (at 25℃)
±3ppm /Year Max.
Packing Unit
3000pcs./Reel
Dimensions[mm]
Send Message
Preview on Mobile
X
Wechat scan code or copy link mobile phone open
X
Copy the link
SMD 1612 Crystal Resonator
