HWHC Series is the newest in open type ferrite wire wound chip inductors. The wire wound ferrite construction supports higher SRF, lower DCR & superior Q values than other ferrite chip inductors.
Features:
* RoHS compliant * Very strong solderability by reflow soldering and soldering iron * Highly accurate dimensions * Can be mounted automatically * Low DCR & better Q value in ferrite series * Terminals are highly resistant to external forces * Highly resistant to mechanical shocks and pressure * Highly reliable in environments of sudden temperature change and humidity
Applications:
* Telecom and datacom applications such as Xdsl * Cable modem * Set-top box * CATV filter/tuner * Wireless LAN, etc
